Description
Plenum box PB-LD2 is used as an accessory for slot diffusers.
Construction
- rectangular reduced casing
- round connection openings with a simple damper
Material
galvanized sheet metal
Accessories
Insulation 6, 10, 13 or 19 mm on the inner side or outside of the casing.
Dimensions
Dimensions B, B1, H and L are variable.
- 1 – slot diffuser
- 2 – plenum box
- 3 – damper
Product Code
PB-LD2
Product
1015 x 77
Dimension B x L
/
-
2x198
Connections
H=320
Plenum box height
ISO 6mm out
Insulation
Dimension B x L
Width and length of the plenum box in mm
Connections
Number and diameter of connection openings in mm
Plenum box height
Plenum box height in mm
Insulation
- ISO in – insulation inside
- ISO out – insulation outside
